Description

StarTech.com 6ft (1.8m) Mini DisplayPort to DVI Cable - Active Mini DP to DVI Adapter Cable - 1080p Video - mDP 1.2 to DVI-D Single Link - mDP or Thunderbolt 1/2 Mac/PC to DVI Monitor, 1.9 m, Mini DisplayPort, DVI-D, Male, Male, Straight

Connect a Mini DisplayPort-equipped PC or MAC to a DVI display, with an active 6ft cable

The MDP2DVIMM6BS 6ft active Mini DisplayPort to DVI adapter cable lets you directly connect your Mini DP video source (such as any of your MacBook® or Microsoft® Surface™ Pro devices with mDP) directly to a DVI monitor or projector, saving the expense of additional adapters.

For guaranteed compatibility with virtually any Mini DisplayPort output the active Mini DP to DVI adapter supports multimode (DP++) as well as single-mode DisplayPort signals. Unlike passive adapters, this ensures the MDP2DVIMM6BS can be used with graphics cards that are not capable of outputting multimode DP++ signals, such as ATI® Eyefinity cards.

Compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt™ I/O port, the adapter supports resolutions up to 1920 x 1200.

The MDP2DVIMM6BS is backed by a 3-year StarTech.com warranty and free lifetime technical support.

Note:

This adapter is not compatible for use with the Apple Cinema Display.

Specifications

BrandSTARTECH
Manufacturer part no.MDP2DVIMM6BS
Our part no.V933019
EAN0065030854931
CategoryCables & Adapters › Display Cables
Weight0.1 kg
Features
Connector 1 form factorStraight
Connector 2 form factorStraight
Cable length1.9 m
Connector 1Mini DisplayPort
Connector 2DVI-D
Connector 1 genderMale
Connector 2 genderMale
DisplayPort version1.2
Dual Link DVINo
Maximum resolution1920 x 1200 pixels
Supported graphics resolutions1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
Product colourBlack
ChipsetParade - PS171
Plug and PlayYes
Converter typeActive
Operational conditions
Operating temperature (T-T)0 - 60 °C
Storage temperature (T-T)-10 - 70 °C
Operating relative humidity (H-H)40 - 85%
Certificates
Compliance certificatesRoHS, CE
CertificationCE, FCC, REACH
Weight & dimensions
Weight100.7 g
Width40 mm
Depth1900 mm
Height16 mm
Packaging data
Package width199 mm
Package depth142 mm
Package height22 mm
Package weight123 g
Packaging content
Quantity per pack1 pc(s)
Logistics data
Harmonized System (HS) code84733080
Master (outer) case width420 mm
Master (outer) case length436 mm
Master (outer) case height426 mm
Products per master (outer) case150 pc(s)
