Description

StarTech.com Cisco SFP-10G-LRM Compatible SFP+ Module - 10GBASE-LRM - 10GbE Multimode Fiber MMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 200m - 1310nm - DDM Cisco Firepower, ASR9000, C9300, Fiber optic, 10000 Mbit/s, SFP+, LC, 220 m, 1310 nm

10 Gbps | Multi Mode Fiber | LC | 200 m (656 ft) | Lifetime Warranty

The SFP10GLRMST is a Cisco SFP-10G-LRM compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco™ brand switches and routers. It delivers dependable 10 GbE connectivity over fiber cable, for 10GBASE-LRM compliant networks, with a maximum distance of up to 200 m (656 ft).

Technical Specifications:

• Wavelength: 1310nm • Maximum Data Transfer Rate: 10 Gbps • Type: Multi Mode Fiber • Connection Type: LC Connector • Maximum Transfer Distance: 200 m (656 ft) • MTBF: 1,535,075 hours • Power Consumption: Less than 1 Watt • Digital Diagnostics Monitoring (DDM): Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

BrandSTARTECH
Manufacturer part no.SFP10GLRMST
Our part no.V933687
EAN0065030864282
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeFiber optic
Maximum data transfer rate10000 Mbit/s
Interface typeSFP+
Multi-mode fiber (MMF) supportedYes
Fiber optic connectorLC
Maximum transfer distance220 m
Wavelength1310 nm
Networking standardsIEEE 802.3ae
Duplex systemFull
Digital Diagnostics Monitoring (DDM)Yes
Fiber ports quantity1
Features
Product colourSilver
Hot-swapYes
Power
Power consumption (typical)1 W
Certificates
Compliance certificatesRoHS
CertificationCE, FCC, UL
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)30 - 75%
Weight & dimensions
Width13.9 mm
Depth58.4 mm
Height12.6 mm
Weight20 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width92 mm
Package depth114 mm
Package height33 mm
Package weight95 g
Logistics data
Master (outer) case width259 mm
Master (outer) case length308 mm
Harmonized System (HS) code85369010
Master (outer) case height203 mm
Products per master (outer) case36 pc(s)
Country of originChina
