Description

StarTech.com Cisco GLC-ZX-SM-RGD Compatible SFP Module - 1000BASE-ZX - 1GbE Single Mode Fiber SMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 70km - 1550nm - DDM Cisco ASR920, IE2000, IE4000, Fiber optic, 1250 Mbit/s, SFP, LC, ZX, 70000 m

1000 Mbps (1 Gbps) | Single Mode Fiber | LC | 70 km (43.5 mi) | Lifetime Warranty

The GLCZXSMRGDST is a Cisco GLC-ZX-SM-RGD compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-ZX compliant networks, with a maximum distance of up to 70 km (43.5 mi).

Technical Specifications:

• Wavelength: 1550 nm • Maximum Data Transfer Rate: 1.25 Gbps • Type: Single Mode Fiber • Connection Type: LC Connector • Maximum Transfer Distance: 70 km (43.5 mi) • MTBF: 1,536,764 hours • Power Consumption: Less than 1 Watt • Digital Diagnostics Monitoring (DDM): Yes

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

BrandSTARTECH
Manufacturer part no.GLCZXSMRGDST
Our part no.V933904
EAN0065030869379
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeFiber optic
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Single-mode fiber (SMF) supportedYes
Fiber optic connectorLC
SFP transceiver standardZX
Maximum transfer distance70000 m
Wavelength1550 nm
Networking standardsIEEE 802.3z
Duplex systemFull
Digital Diagnostics Monitoring (DDM)Yes
Features
Product colourSilver
Housing materialAluminium
Hot-swapYes
Mean time between failures (MTBF)1536764 h
Power
Power consumption (typical)1 W
Certificates
Compliance certificatesCE, RoHS
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)5 - 95%
Weight & dimensions
Width13.7 mm
Depth56.6 mm
Height12.5 mm
Weight16 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width91 mm
Package depth112 mm
Package height33 mm
Package weight48 g
Logistics data
Master (outer) case width200 mm
Master (outer) case length300 mm
Harmonized System (HS) code85369010
Master (outer) case height166 mm
Products per master (outer) case15 pc(s)
