Description

StarTech.com Cisco SFP-10GB-TC Compatible SFP+ Module - 10GBASE-T - SFP to RJ45 Cat6/Cat5e - 10GE Gigabit Ethernet SFP+ - RJ-45 30m - Cisco Firepower, ASR1000, ASR9000, Copper, 10000 Mbit/s, SFP+, 30 m, IEEE 802.3an, Full, Half

10Gbps | Copper | RJ45 | 30 m (100 ft) | Lifetime Warranty

The SFP10GBTCST is a Cisco compatible copper transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 10 GbE connectivity over copper cable, for 10GBASE-T compliant networks, with a maximum distance of up to 30 m (98.4 ft).

Technical Specifications:

• Maximum Data Transfer Rate: 10 Gbps • Type: Copper • Connection Type: RJ45 Connector • Maximum Transfer Distance: 30 m (98.4 ft) • MTBF: 4,598,430 hours • Digital Diagnostics Monitoring (DDM): No

This SFP+ copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

BrandSTARTECH
Manufacturer part no.SFP10GBTCST
Our part no.V934413
EAN0065030880206
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeCopper
Maximum data transfer rate10000 Mbit/s
Interface typeSFP+
Maximum transfer distance30 m
Networking standardsIEEE 802.3an
Duplex systemFull, Half
Auto MDI/MDI-XYes
Digital Diagnostics Monitoring (DDM)No
Features
Product colourSilver
Housing materialZinc steel
Hot-swapYes
Mean time between failures (MTBF)4598430 h
Brand compatibilityCisco
Power
Power consumption (typical)2.3 W
Certificates
Compliance certificatesRoHS
CertificationCE, FCC
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 90 °C
Operating relative humidity (H-H)0 - 95%
Weight & dimensions
Width13.4 mm
Depth69.8 mm
Height14 mm
Weight58 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width120 mm
Package depth75 mm
Package height34 mm
Logistics data
Master (outer) case width643 mm
Master (outer) case length348 mm
Harmonized System (HS) code85369010
Master (outer) case height291 mm
Products per master (outer) case150 pc(s)
Country of originTaiwan
