Description

StarTech.com 2-Port HDMI Splitter with HDR - 4K 60Hz, HDMI, 2x HDMI, 3840 x 2160 pixels, Black, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160, 720p, 1080p

1 In 2 Out Video Splitter | HDMI 2.0 | HDR | 2-Year Warranty

This 2-Port 4K HDMI splitter connects your HDMI video source to two HDMI displays at the same time, without distorting or degrading your video signal. For dependable performance, the splitter features a durable metal housing that provides passive cooling.

True 4K at 60Hz and HDR

With transmission bandwidth up to 18Gbps, this HDMI splitter is fully compatible with your HDMI 2.0 equipment, supporting UHD resolutions up to 4096x2160 (4K) at 60Hz. For smooth video and color transitions, the splitter offers 4:4:4 chroma subsampling, so every pixel gets its own unique color.

The splitter also supports High Dynamic Range (HDR) imaging, offering a greater luminosity than standard digital imaging.

Widely Compatible

The 2-way HDMI splitter supports HDCP 2.2 and is backward compatible with 4K 30Hz and 1080p displays. This ensures that it will work with almost any HDMI source, or destination device such as computers, Blu-ray players, monitors, TVs and projectors. Perfect for digital signage applications, where equipment may vary throughout your site.

Easy Installation

For hassle-free setup, the 1x2 HDMI splitter offers easy plug-and-play installation. The splitter also saves you setup time by automatically passing EDID between your video source and the display attached to port 1, ensuring settings like native resolution and refresh rate are configured properly.

ST122HD202 is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Specifications

BrandSTARTECH
Manufacturer part no.ST122HD202
Our part no.V934416
EAN0065030880404
CategoryCables & Adapters › HDMI Cables & Extenders
Weight0.4 kg
Ports & interfaces
Video port typeHDMI
Video out2x HDMI
HDMI version2.0
Video ports quantity2
Features
Product colourBlack
Maximum resolution3840 x 2160 pixels
HDCPYes
Supported graphics resolutions1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160
Power LEDYes
Plug and PlayYes
Supported video modes720p, 1080p
LED indicatorsYes
CertificationCE, FCC
Power
AC input voltage100 - 240 V
Input current0.2 A
Output voltage5 V
Output current1 A
Power consumption (typical)5 W
Weight & dimensions
Dimensions (WxDxH)56 x 100 x 17 mm
Weight159 g
Packaging data
Package width154 mm
Package depth217 mm
Package height58 mm
Package weight402 g
Packaging content
User guideYes
AC adapter includedYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)20 - 90%
Technical details
Supported audio channels7.1
Compliance certificatesRoHS
Logistics data
Harmonized System (HS) code85176990
Master (outer) case width462 mm
Master (outer) case length307 mm
Master (outer) case height485 mm
Products per master (outer) case30 pc(s)
