StarTech.com 4-Bay USB to SATA Hard Drive Docking Station, USB 10Gbps, External 2.5" & 3.5" SSD / HDD Dock, SATA III, Hot-Swap Hard Drive Bay, Top-Loading, HDD, SSD, Serial ATA, Serial ATA II, Serial ATA III, 2.5,3.5", 10 TB, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, Black

External SSD/HDD Docking Station | USB 3.2 Gen 2 (10 Gbps) to SATA I/II/III

This 4-bay SATA HDD docking station lets you access up to four solid-state drives or hard drives simultaneously over USB 10Gbps, and hot swap drives with ease. Ideal for IT professionals, the docking station provides large data capacity and fast file transfers, helping you manage your workflow more efficiently.

Save time accessing and managing your data

When you're managing a large number of drives, the HDD/SSD docking station saves you time. Quickly dock and swap your drives for disk imaging, data recovery from failing drives, data backups, or other tasks.

The hard drive docking station also has SMART support, for accessing important drive information such as hours in use, number of power cycles, and disk health.

Fast data transfers

With USB 3.2 Gen 2, the HDD docking station lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.

Convenient compatibility

The hard drive docking station includes a USB Type-C cable, for connecting to USB-C equipped laptops and devices, and a USB Type-A cable, for backward compatibility with your existing USB 3.0, 2.0 and 1.x devices.

The docking station also works with 2.5" and 3.5" IDE hard drives, mSATA drives and M.2 drives using a compatible StarTech.com adapter:

IDE hard drives: Use StarTech.com adapter SAT2IDEADP SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks

mSATA drives: Use StarTech.com adapter SAT32MSAT257 mSATA SSD to 2.5in SATA Adapter Converter

M.2 drives: Use StarTech.com adapter SAT32M225 M.2 NGFF SSD to 2.5in SATA Adapter Converter

Specifications

BrandSTARTECH
Manufacturer part no.SDOCK4U313
Our part no.V934434
EAN0065030870672
CategoryCables & Adapters › USB Cables & Adapters
Weight2.3 kg
Hard drive
Storage media typeHDD, SSD
Storage drive interfaceSerial ATA, Serial ATA II, Serial ATA III
Storage drive sizes supported2.5,3.5"
Number of storage drives supported4
Maximum storage capacity10 TB
Ports & interfaces
Host interfaceUSB 3.2 Gen 2 (3.1 Gen 2) Type-C
USB 3.2 Gen 2 (3.1 Gen 2) ports quantity1
Features
Product colourBlack
MaterialPlastic
Maximum data transfer rate10 Gbit/s
Hot-swapYes
Plug and PlayYes
S.M.A.R.T. supportYes
TRIM supportYes
Number of connectivity cycles10000
LED indicatorsActivity, Power
UASP supportYes
Cooling
Built-in fanYes
Number of fans2 fan(s)
Fan diameter6 cm
Bearing typeSleeve bearing
Power
Power consumption (standby)78 W
AC input voltage100 - 240 V
Input current2 A
Output voltage12 V
Output current6.5 A
Weight & dimensions
Width171 mm
Depth291 mm
Height87 mm
Weight1 kg
Packaging data
Package width170 mm
Package depth340 mm
Package height210 mm
Package weight2.4 kg
Packaging content
AC adapter includedYes
Cables includedUSB, USB Type-C
Included power plug typesANZ, EU, JP, NA, UK
Quick installation guideYes
Operational conditions
Operating temperature (T-T)5 - 35 °C
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)20 - 80%
Other features
Noise level19.04 dB
ChipsetVIA Labs - VL820, VIA Labs - VL715
Mean time between failures (MTBF)30000 h
Compliance certificatesCE, RoHS
Logistics data
Harmonized System (HS) code84733080
Master (outer) case width354 mm
Master (outer) case length356 mm
Master (outer) case height470 mm
Products per master (outer) case4 pc(s)
