Description

StarTech.com ~HDMI Over IP Receiver for ST12MHDLAN2K - Video Wall Support - 1080p, 1920 x 1080 pixels, AV receiver, 100 m, Wired, Black

HDMI® Video Over Cat5e or Cat6 |Scale to Multiple Displays |Mobile Control AppThis HDMI over IP receiver works with the HDMI Over IP Extender Kit (ST12MHDLAN2K, sold separately) and an Ethernet switch (sold separately), to receive HDMI video over your local area network (LAN) in remote locations, using Cat5e or Cat6 cabling. You can use additional receivers to distribute the HDMI signal to multiple locations or combine your remote displays to create a video wall.Highly ScalableIn a point-to-multipoint (one source to many screens) or multipoint-to-multipoint (many sources to many screens) configuration, you can output video to over 100 additional displays. Each display requires a receiver. Remote control of serial devices is supported through RS232 extension.Resolutions Up to 1080p, with AudioWith support for video resolution up to 1080p (1920 x 1080 at 60Hz), the transmitter also supports digital and analog audio to the receiver and analog audio from the receiver to the transmitter.Mobile Control with Included AppThe kit includes an easy-to-use online app to manage your IP video distribution.The app is available on iOS for your iPhone or iPad, Android for your smartphone or tablet, and Google Chrome browser for your desktop.Hassle-Free InstallationThe HDMI over IP receiver includes optional shelf-mounting hardware. It uses Cat5e or Cat6 cables and works with existing network infrastructures, eliminating the expense of running proprietary cables.ST12MHDLAN2R is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage

Specifications

BrandSTARTECH
Manufacturer part no.ST12MHDLAN2R
Our part no.V934463
EAN0065030878463
CategoryCables & Adapters › HDMI Cables & Extenders
Weight1.3 kg
Features
TypeAV receiver
Maximum resolution1920 x 1080 pixels
Cable types supportedCat5e, Cat6
Maximum transfer distance100 m
Audio output channels7.1 channels
LED indicatorsLink, Power, Status
Supported graphics resolutions1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1360 x 768 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
MaterialAluminium
Rack mountingYes
Daisy chainYes
Rubber feetYes
Product colourBlack
CertificationCE, FCC, TAA
Ports & interfaces
Connectivity technologyWired
RJ-45 input ports1
Number of HDMI outputs1
Audio input3.5 mm
Audio output3.5 mm
RJ-11 ports quantity2
Remote (IR) input1
Remote (IR) output1
Power
AC input voltage100 - 240 V
Operating voltage12 V
Input current0.6 A
Output current1.5 A
Power consumption (typical)10 W
External power adapterYes
Power plug typeType M
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width118 mm
Depth131 mm
Height31 mm
Weight80 g
Packaging data
Package width208 mm
Package depth295 mm
Package height64 mm
Package weight175 g
Packaging content
Cables includedLAN (RJ-45), Phone (RJ-11)
Included power plug typesANZ, EU, JP, NA, UK
ManualYes
IR blaster includedYes
IR receiver includedYes
Mounting kitYes
Technical details
Audio supportYes
Compliance certificatesRoHS
Logistics data
Master (outer) case width323 mm
Master (outer) case length410 mm
Master (outer) case height275 mm
Products per master (outer) case6 pc(s)
