Description

StarTech.com Citrix 455883-B21 Compatible QSFP+ Module - 40GBASE-SR4 - Multi Mode Fiber (MMF) - 40GE Gigabit Ethernet QSFP+ - MPO 100 m - 850nm - DDM~Citrix 3013936-E2 Compatible QSFP+ Module - 40GBASE-SR4 - Multi Mode Fiber (MMF) - 40GE Gigabit Ethernet QSFP+ - MPO 100m - 850nm - DDM, Fiber optic, 40000 Mbit/s, QSFP+, MPO, SR4, 100 m

40 Gbps | Multi Mode Fiber | MPO | 100 m (328 ft) | Lifetime Warranty

The 3013936-E2-ST is a Citrix® 3013936-E2 compatible fiber transceiver module that has been designed, programmed and tested to work with Citrix brand switches and routers. It delivers dependable 40 GbE connectivity over fiber cable, for 40GBASE-SR4 compliant networks, with a maximum distance of up to 100 m (328 ft).

Technical Specifications :

Wavelength: 850nm

Maximum Data Transfer Rate: 40 Gbps

Type: Multi Mode

Connection Type: MPO

Maximum Transfer Distance: 100 m (328 ft)

MTBF: 244,610,582 hours

Power Consumption:

This QSFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Specifications

BrandSTARTECH
Manufacturer part no.3013936-E2-ST
Our part no.V934761
EAN0065030886888
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeFiber optic
Maximum data transfer rate40000 Mbit/s
Interface typeQSFP+
Multi-mode fiber (MMF) supportedYes
Fiber optic connectorMPO
SFP transceiver standardSR4
Maximum transfer distance100 m
Wavelength850 nm
Fiber ethernet cabling technology40GBASE
Features
Product colourSilver
Hot-swapYes
Mean time between failures (MTBF)244610582 h
Brand compatibilityCitrix
Compatible products3013936-E2
Power
Power consumption (typical)0.7 W
Certificates
Compliance certificatesRoHS
CertificationFCC, CE, UR
Weight & dimensions
Width90 mm
Depth120 mm
Height31 mm
Weight50 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width130 mm
Package depth185 mm
Package height45 mm
Package weight37.4 g
Logistics data
Master (outer) case width340 mm
Master (outer) case length420 mm
Harmonized System (HS) code85369010
Master (outer) case height350 mm
Products per master (outer) case36 pc(s)
